MikroTik: Bridge Interface with Multiple Ports

Introduction

Setting up a bridge interface on a MikroTik device allows you to unify multiple physical interfaces into a single logical network. This is especially useful for connecting wired and wireless networks or managing traffic across various Ethernet ports. In this guide, you’ll learn how to configure a bridge interface on your MikroTik device and add multiple interfaces, including Ethernet and wireless.

More information about bridge intraface on MikroTik devices you can finde on the link.

Why Use a Bridge Interface?

A bridge interface connects multiple ports into a single broadcast domain, allowing seamless communication among devices. Use cases include:

Combining wired and wireless networks.
Extending the network across multiple physical interfaces.
Simplifying network management

Mikrotik Schema for Bridge Setup — Create a Bridge Interface and add multiple Interface to it.

Video Tutorial How to create bridge interaface and add multiple ports

Step-by-Step Bridge Configuration with WinBox

Step 1: Log in to MikroTik Router

Access your router via the MikroTik WinBox application or the web interface. Use your credentials to log in.

Step 2: Navigate to the `Bridge`

Go to the Bridge menu in Winbox.Click Add (+) to create a new bridge.Name the bridge, e.g., intern

Step 3: Add Interfaces to the Bridge

Go to the Ports tab under the Bridge menu.
Click Add (+) to add interfaces.
Select interfaces such as eth2, eth3, eth4, eth5, and wlan.
Assign each to the bridge you created (e.g., LAN-Bridge).

Add Interface eth2 in the Bridge — Add Interface in the Bridge

Step 4: Verify Configuration

Go to the Bridge menu and check the status.
Ensure that all selected interfaces are listed under the bridge.
Test connectivity between devices connected to the ports.

Check a Bridge Interface with Winbox Application

Check if the interfaces are add in the Bridge

Configuration via CLI

Using the MikroTik Command Line Interface (CLI) is an efficient way to configure a static IP address. Here’s a step-by-step guide:

Step 1: Copy following script in the terminal

/interface bridge
add fast-forward=no name=intern

/interface bridge port
add bridge=intern interface=ether2
add bridge=intern interface=wlan1
add bridge=intern interface=ether3
add bridge=intern interface=ether4
add bridge=intern interface=ether5
